Vertical Form Fill Seal Packaging Machine

Name: Vertical Form Fill Seal Packaging Machine
Brand: Alpha Pack
Price: 20000 USD

China Vertical Form Fill Seal Packaging Machine wholesale

Brand Name : Alpha Pack

Model Number : PM-420

Certification : CE

Place of Origin : China

MOQ : 1 set

Price : USD20000-25000

Payment Terms : T/T L/C

Supply Ability : 20 sets per month

Delivery Time : 50 workdays

Packaging Details : standard export wooden case

name : Automatic vertical FFS machine

keyword : VFFS machine

speed : 35-40 ppm

film : laminated film

material : Painting Case or 304 stainless steel

Contact Now

Automatic Vertical Form Fill Seal Packing Machine

Model: PM-420

Model	PM-420
Max measuring range	1000ml
Bag length(mm)	80-300
Bag width (mm)	80-200
Film width (mm)	180-430
Speed (bag/min)	30-40
Power supply	1ph/220V, 2.5kw

Application:

Automatic packaging of granule powder and powder in formed bag for the food, pharmaceutical, chemical industries etc.

Features:

1. The machine can automatically finish the products conveying, measuring, feeding, filling and bag forming, bag printing, bag sealing & cutting;

2. Servo motor driven, twin-belt film pulling system;

3. High sensitive sensor can trace color mark accurately;

4. PLC control system combined with touch screen, can easily set and change the packing parameters, daily production output and self-diagnostic machine error can be viewed directly from the screen;

5. PID temperature controller monitors heat sealing temperature within ±1℃.

6. Selected electrical and pneumatic components from reliable international manufacturer.

7. CE certificated can comply with CE standard.

Optional parts

1. Gusset forming device;

2. printer;

3. Pouch top hole pouch;

4. #340 stainless steel machine case.
